5
XC20
Typical Unit Parts Arrangement
GROUND LUG
OUTDOOR
CONTROL
INVERTER REACTOR
DC INVERTER
CONTROL
CONTACTOR-SPST
GROUND LUG
CONTACTOR-SPST
OUTDOOR CONTROL
INVERTER NOISE FILTER
INVERTER REACTOR
CONTROL PANEL FOR
XC20-024 AND -036
CONTROL PANEL FOR
XC20-048 AND -060
DC INVERTER
CONTROL
Figure 1. Control Panel Components
