Lennox XC25-024-230-01 User Manual

2
XC25
I. OVERVIEW
Model Number identification
C 25 XXX
− −
Unit Type
C = AIR CONDITIONER
Series
Nominal Cooling Capacity
024 = 2 tons
036 = 3 tons
048 = 4 tons
060 = 5 tons
Minor Revision Number
230
Voltage
230 = 208/230V-1ph-60hz
Refrigerant Type
X = R-410A
X
-02
Typical Serial Number Identification
8 09 C
Year Code
08 = 2008
09 = 2009
10 = 2010
Month Code
A = January
B = February
C = March
05716
5 (or 6) Digit Unique Number
Location Code
19 = Saltillo, Mexico
58 = Marshalltown, IA
5
Specifications
Model Number
Unit Outdoor Fan
Sound Rating Number (dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
Maximum Minimum
XC25-024-230-01 70 59 13 lbs, 10 oz 5 26
Model Number
Unit Outdoor Fan
Sound Rating Number (dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
Maximum Minimum
XC25-036-230-01 73 59 10 lbs, 12 oz 5 26
Model Number
Unit Outdoor Fan
Sound Rating Number (dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
Maximum Minimum
XC25-048-230-01 74 66 14 lbs, 9 oz 5 26
Model Number
Unit Outdoor Fan
Sound Rating Number (dB)
1
Factory Refrigerant
Charge
2
Number of Blades Diameter - inches.
Maximum Minimum
XC25-060-230-01 74 64 14 lbs, 8 oz 5 26
1
Tested according to AHRI Standard 270-2008 test conditions.
2
Factory refrigerant charge is sufficient for refrigerant line lengths up to 15 feet.

Lennox XC25-024-230-01 Specifications

General

Brand	Lennox
Model	XC25-024-230-01
Category	Air Conditioner
Language	English
