Lenovo 14e Chromebook Hardware Maintenance Manual

Step 3. Remove the lower case.
3
Figure 5. Remove the lower case
Refer to “Major FRUs and CRUs” on page 30 to look up details about the following replacement part:
Lower case
Remove the battery pack
Make sure the following FRU (or CRU) has been removed.
“Remove the lower case” on page 36
Step 1. Remove the 4 screws.
1
1
1
1
Figure 6. Remove the 4 screws
Screw specifications Number of screws Color
1 M2.0 x 5.0 4
Silver
Attention: Do not directly detach the battery pack connector because there is no sufficient space
(only 12 mm) for detachment before removing the 4 screws.
Chapter 5. Removing a FRU or CRU 37

Lenovo 14e Chromebook Specifications

General

Processor	AMD A4-9120C
Storage	32GB eMMC
Operating System	Chrome OS
Battery Life	Up to 10 hours
Graphics	Integrated AMD Radeon R4 Graphics
Display	14" HD (1366 x 768) Anti-Glare
Memory	4GB DDR4
Dimensions	17.7 mm
Ports	2 x USB-C, microSD card reader, headphone/microphone combo jack
Wireless	802.11ac WiFi, Bluetooth 4.2
Weight	1.48 kg (3.26 lbs)
