Lenovo 14e Chromebook Hardware Maintenance Manual

7
6
Figure 41. Detach the EDP cable connector and remove the LCD panel
Refer to “LCD FRUs and CRUs” on page 32 to look up details about the following replacement parts:
LCD bezel
Hinge cover
Hinges
Removable tapes
LCD panel
Remove the camera board
Make sure the following FRUs (or CRUs) have been removed.
“Remove the lower case” on page 36
“Remove the battery pack” on page 37
“Remove the upper case (with keyboard)” on page 47
“Remove the LCD panel” on page 51
Step 1. Detach the camera connector.
54
Hardware Maintenance Manual

Lenovo 14e Chromebook Specifications

General

Processor	AMD A4-9120C
Storage	32GB eMMC
Operating System	Chrome OS
Battery Life	Up to 10 hours
Graphics	Integrated AMD Radeon R4 Graphics
Display	14" HD (1366 x 768) Anti-Glare
Memory	4GB DDR4
Dimensions	17.7 mm
Ports	2 x USB-C, microSD card reader, headphone/microphone combo jack
Wireless	802.11ac WiFi, Bluetooth 4.2
Weight	1.48 kg (3.26 lbs)
