Lenovo 14e Chromebook Hardware Maintenance Manual

Step 4. Open the right hinge.
7
Figure 15. Open the right hinge
Step 5. Remove the I/O board.
8
Figure 16. Remove the I/O board
Refer to “Major FRUs and CRUs” on page 30 to look up details about the following replacement parts:
I/O bracket (right)
I/O board
Remove the speakers
Make sure the following FRUs (CRUs) have been removed.
“Remove the lower case” on page 36
“Remove the battery pack” on page 37
42
Hardware Maintenance Manual

Lenovo 14e Chromebook Specifications

General

Processor	AMD A4-9120C
Storage	32GB eMMC
Operating System	Chrome OS
Battery Life	Up to 10 hours
Graphics	Integrated AMD Radeon R4 Graphics
Display	14" HD (1366 x 768) Anti-Glare
Memory	4GB DDR4
Dimensions	17.7 mm
Ports	2 x USB-C, microSD card reader, headphone/microphone combo jack
Wireless	802.11ac WiFi, Bluetooth 4.2
Weight	1.48 kg (3.26 lbs)
