Lenovo 14e Chromebook Hardware Maintenance Manual

3
3
Figure 28. Open the hinges
Step 4. Remove the upper case in the arrow direction shown below.
4
Figure 29. Remove the upper case
Attention: Do not pull out the upper case before detaching the EDP cable connector. Otherwise
the cable may be damaged.
Refer to “Major FRUs and CRUs” on page 30 to look up details about the following replacement part:
Upper case (with keyboard)
Remove the touchpad assembly
Make sure the following FRUs (or CRUs) have been removed:
“Remove the lower case” on page 36
“Remove the battery pack” on page 37
Step 1. Detach the touchpad connector from the system board.
48
Hardware Maintenance Manual

Lenovo 14e Chromebook Specifications

General

Processor	AMD A4-9120C
Storage	32GB eMMC
Operating System	Chrome OS
Battery Life	Up to 10 hours
Graphics	Integrated AMD Radeon R4 Graphics
Display	14" HD (1366 x 768) Anti-Glare
Memory	4GB DDR4
Dimensions	17.7 mm
Ports	2 x USB-C, microSD card reader, headphone/microphone combo jack
Wireless	802.11ac WiFi, Bluetooth 4.2
Weight	1.48 kg (3.26 lbs)
