1020 Hard disk drive (2.5-inch) and HDD rubber rails
Note: This procedure is only for models with a 2.5-inch hard disk drive.
Attention
v Do not drop or apply any shock to the hard disk drive. The hard disk
drive is sensitive to physical shock. Incorrect handling can cause damage
and permanent loss of data.
v Before removing the drive, have the user make a backup copy of all the
information on the drive if possible.
v Never remove the drive while the system is operating or is in suspend
mode.
For access, remove following FRU:
v “1010 Battery pack” on page 60
1
2
Step Screw (quantity) Color Torque
1 M3 × 3 mm, wafer-head, nylon-coated (1) Black 0.196 Nm
(2 kgfcm)
3
Removing and replacing a FRU
ThinkPad X60, X60s, X61, and X61s 61
