ideapad FLEX 4-1470/ideapad FLEX 4-1435/ideapad FLEX 4-1480/ideapad
FLEX 4-1570/ideapad FLEX 4-1580 Hardware Maintenance Manual
1020 Battery pack
DANGER
Only use the battery specied in the parts list for your computer. Any other battery
could ignite or explode.
Foraccess,removethisFRU:
• “1010Basecover”onpage33
Figure 2. Removal steps of battery pack
Detachthebatterypackconnectorinthedirectionshownbyarrow
1
,remove
thescrews
2
.
ideapadFLEX4-1570:
b
b
a
b
ideapadFLEX4-1470:
b
b
a
b
Step Screw (quantity) Color Torque
2
M2×3.5mm,Phillips-head,nylok-coated
(3)battery---logup
Silver 1.85+/-0.15kgf-cm

Lenovo ideapad FLEX 4 Specifications

General

Graphics	Intel HD Graphics 520
Display	14" FHD (1920 x 1080) IPS Multi-touch
RAM	16GB DDR4
Storage	512GB SSD or 1TB HDD
Operating System	Windows 10 Home
Ports	2 x USB 3.0, 1 x USB 2.0, HDMI, Audio Combo Jack
Wireless	Wi-Fi 802.11ac, Bluetooth 4.0
