Lenovo ideapad FLEX 4 User Manual

56
ideapad FLEX 4-1470/ideapad FLEX 4-1435/ideapad FLEX 4-1480/ideapad
FLEX 4-1570/ideapad FLEX 4-1580 Hardware Maintenance Manual
1110 LCD unit
Foraccess,removetheseFRUsinorder:
• “1010Basecover”onpage33
• “1020Batterypack”onpage36
• “1030PCIExpressMiniCardforwirelessLAN”onpage38
• “1050Speakers”onpage42
• “1060Harddiskdrive”onpage43
• “1070FanassemblyandHeatSinkassembly”onpage45
• “1080IOboard,DC-incable”onpage49
• “1090Systemboard”onpage51
• “1100Uppercase”onpage53
Figure 11. Removal steps of LCD unit
Removethescrews
1
.
a
a
Step Screw (quantity) Color Torque
1
M2×3.5mm,Phillips-head,nylok-coated(2)
lcdbezel---lcdbrk---lcdcover
Silver 1.85+/-0.15kgf-cm
