Rear view of the chassis
(If the rear view configuration shown in this chapter is different from the rear of your
computer, please refer to the rear of your computer.)
Voltage selection switch (selected models only)
Power connector
DisplayPort connector (selected models only)
HDMI connector (selected models only)
On-board VGA connector
USB 3.0 connector (selected models only)
USB 2.0 connector
Ethernet connector
Audio connectors
PCI Express X 16 graphics adapter slot (some models are equipped with a
graphics card)
PCI Express X 1 adapter slots (some models are equipped with a WIFI card
or TV tuner card)
