Lenovo Tab P10 Series User Manual

Hardware Maintenance Manual
28
1040 Speakers
For access, remove these FRUs in order:
• “1010 Card tray” on page 24
• “1020 Battery cover” on page 25
• “1030 Battery pack” on page 26
Figure 4. Removal steps of speakers
Remove the screws .
Lenovo TB-X705F
Lenovo TB-X705L
Step Screw (quantity) Color Torque
M1.4 × 2.5 mm, Phillips head(11) Black Appr. 0.6 kgf·cm
Step Screw (quantity) Color Torque
M1.4 × 2.5 mm, Phillips head(10) Black Appr. 0.6 kgf·cm
M1.4 × 3.5 mm, Phillips head(1) Silver Appr. 0.6 kgf·cm
a
1
1
1 111
1
1
1
1
1
a
1
1
1 11
1
1
1
2
1
1
a
b

Lenovo Tab P10 Series Specifications

General

Resolution	1920 x 1200 pixels
Processor	Qualcomm Snapdragon 450
Battery	7000 mAh
Rear Camera	8MP
Front Camera	5MP
RAM	3GB
Storage	32GB
Connectivity	Bluetooth 4.2, USB Type-C
