Lenovo Tab P10 Series User Manual

Lenovo Tab P10
33
1060 SIM card slot and vibrator module
For access, remove these FRUs in order:
• “1010 Card tray” on page 24
• “1020 Battery cover” on page 25
• “1030 Battery pack” on page 26
• “1040 Speakers” on page 28
• “1050 Fingerprint module and POGOPIN FPC” on page 31
Figure 6. Removal steps of SIM card slot and vibrator module
Detach the connector , and remove the screws .
Lenovo TB-X705F
Lenovo TB-X705L
Step Screw (quantity) Color Torque
M1.4 × 1.8 mm, Phillips head(4) Silver Appr. 0.6 kgf·cm
a b
2
2
2
2
1
2
2
2
2
1
a

Lenovo Tab P10 Series Specifications

General

Resolution	1920 x 1200 pixels
Processor	Qualcomm Snapdragon 450
Battery	7000 mAh
Rear Camera	8MP
Front Camera	5MP
RAM	3GB
Storage	32GB
Connectivity	Bluetooth 4.2, USB Type-C
