Lenovo ThinkCentre M80q Hardware Maintenance Manual

8998 Not enough shadow RAM resources
for OPTION ROM, not all devices
initialized. Suggest to remove some
add-on cards, or change to UEFI
mode in BIOS setup.
This error message is displayed
when the shadow RAM resources
for option ROM are insufficient.
If the legacy option ROM is
insufficient, remove some add-in
cards.
For the system that supports
UEFI, set UEFI as the first priority.
8999
Not enough PCIe/PCI MMIO
resources. Currently only one video
card is enabled. Remove some PCIe
cards.
This error message is displayed
when the PCIe/PCI MMIO
(memory mapped input/output)
resources are insufficient.
Remove some add-in cards.
Miscellaneous error conditions
Message/Symptom
FRU/Action
Changing display colors Display/Monitor
Computer will not power-off. See “Hard disk drive boot
error” on page 32.
1. Power Switch
2. System Board
3. Riser card, if installed.
Computer will not RPL from server
1. Ensure that the network is in startup sequence as the
first device or the first device after diskette.
2. Ensure that the network adapter is enabled for RPL.
3. Network adapter (Advise network administrator of
new MAC address)
Computer will not perform a Wake On LAN
®
(if applicable)
1. Check the power supply and signal cable
connections to the network adapter.
2. Ensure that the operating system settings are set to
enable Wake on LAN.
3. Ensure that the Wake On LAN feature is enabled in
Setup/Configuration.
4. Ensure that the network administrator is using the
correct MAC address.
5. Ensure no interrupt or I/O address conflicts.
6. Network adapter (advise network administrator of
new MAC address)
Dead computer. See “Hard disk drive boot error” on page
32.
1. Power Supply
2. System Board
Diskette drive in-use light remains on or does not light
when drive is active.
1. Diskette Drive
2. System Board
3. Diskette Drive Cable
Blank screen except for flashing cursor.
1. System Board
2. Primary Hard Disk Drive
3. Hard Disk Drive Cable
Chapter 4. Service checkout and symptom-to-FRU index 35

Lenovo ThinkCentre M80q Specifications

General

Audio chip	Realtek ALC233VB
Audio system	High Definition Audio
Product type	Mini PC
Number of speakers	1
Motherboard chipset	Intel Q470
Password protection type	HDD, Power on, Supervisor
Volume	1 L
Product color	Black
Placement supported	Vertical
Cable lock slot type	Kensington
Processor cache	16 MB
Processor cores	8
Processor family	Intel® Core™ i7
Processor threads	16
Processor frequency	2 GHz
Processor cache type	Smart Cache
Configurable TDP-down	25 W
Processor manufacturer	Intel
Processor boost frequency	4.5 GHz
Configurable TDP-down frequency	1.3 GHz
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory channels	Dual-channel
Memory clock speed	2933 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	1 x 16 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express 3.0
Storage media	SSD
SSD form factor	M.2
Optical drive type	No
Total storage capacity	512 GB
Operating system language	DEU, DUT, ENG, FRE, ITA
Operating system architecture	64-bit
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 630
On-board graphics card family	Intel® UHD Graphics
Power supply	135 W
Antenna type	2x2
LAN controller	Intel® I219-LM
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.1
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Certification	EPEAT Silver, ENERGY STAR 8.0, ErP Lot 3, TCO Certified 8.0, RoHS, MIL-STD-810H
Sustainability certificates	ENERGY STAR, TCO, EPEAT Silver, RoHS

Weight and Dimensions

Depth	183 mm
Width	179 mm
Height	31 mm
Weight	1250 g
