Lenovo ThinkCentre M80q Hardware Maintenance Manual

d. All connected devices are enabled in UEFI BIOS.
2. Use an antivirus program to see if the computer has been infected by a virus. If the program detects a
virus, remove the virus.
3. Go to “Self-help resources” on page 39 and follow the instructions for the type of problem you are
experiencing.
4. Run the diagnostic program.
5. Recover your operating system. See “Self-help resources” on page 39.
6. If the problem persists, contact Lenovo.
UEFI diagnostic program
A UEFI diagnostic program is preinstalled on the computer. It enables you to test memory modules and
internal storage devices, view system information, and check and recover bad sectors on internal storage
devices.
To run the UEFI diagnostic program, do the following:
1. Turn on the computer. If the computer cannot be turned on, go to “Basic procedure for resolving
computer problems” on page 37. If an error code is displayed, go to “Symptom-to-FRU index” on page
32 for error code descriptions and troubleshooting hints.
2. Repeatedly press and release the F10 key when turning on the computer. The main screen of the UEFI
diagnostic program is displayed.
3. Follow the instructions on the screen to use the diagnostic program.
The options on the main screen are as follows:
Table 1. Options on the main screen of the UEFI diagnostic program
DIAGNOSTICS TOOLS
• CPU [U]
• DISPLAY [D]
• MEMORY [E]
• MOTHERBOARD [H]
• PCI EXPRESS [P]
• STORAGE [S]
• AUDIO [Z]
• OPTICAL [O]
• RUN ALL [R]
• SYSTEM INFORMATION [F1]
• BAD BLOCK RECOVERY [F3]
• SMART INFORMATION [F5]
Note: The options on the main screen might vary, depending on the hardware configuration and the UEFI
diagnostic program version preinstalled on the computer.
Lenovo diagnostic tools
For information about Lenovo diagnostic tools, go to:
https://pcsupport.lenovo.com/lenovodiagnosticsolutions
The Vantage app
The Vantage app is preinstalled on your computer. To diagnose problems with the Vantage app:
1. Type Vantage in the Windows search box and press Enter.
38
M70q and M80q Hardware Maintenance Manual

Lenovo ThinkCentre M80q Specifications

General

Audio chip	Realtek ALC233VB
Audio system	High Definition Audio
Product type	Mini PC
Number of speakers	1
Motherboard chipset	Intel Q470
Password protection type	HDD, Power on, Supervisor
Volume	1 L
Product color	Black
Placement supported	Vertical
Cable lock slot type	Kensington
Processor cache	16 MB
Processor cores	8
Processor family	Intel® Core™ i7
Processor threads	16
Processor frequency	2 GHz
Processor cache type	Smart Cache
Configurable TDP-down	25 W
Processor manufacturer	Intel
Processor boost frequency	4.5 GHz
Configurable TDP-down frequency	1.3 GHz
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory channels	Dual-channel
Memory clock speed	2933 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	1 x 16 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express 3.0
Storage media	SSD
SSD form factor	M.2
Optical drive type	No
Total storage capacity	512 GB
Operating system language	DEU, DUT, ENG, FRE, ITA
Operating system architecture	64-bit
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 630
On-board graphics card family	Intel® UHD Graphics
Power supply	135 W
Antenna type	2x2
LAN controller	Intel® I219-LM
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.1
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Certification	EPEAT Silver, ENERGY STAR 8.0, ErP Lot 3, TCO Certified 8.0, RoHS, MIL-STD-810H
Sustainability certificates	ENERGY STAR, TCO, EPEAT Silver, RoHS

Weight and Dimensions

Depth	183 mm
Width	179 mm
Height	31 mm
Weight	1250 g
