Lenovo ThinkCentre M80q Hardware Maintenance Manual

Message/Symptom
FRU/Action
Serial or parallel connector device failure (adapter
connector)
1. External Device Self-Test OK?
2. External Device
3. Cable
4. Alternate Adapter
5. System Board
Some or all keys on the keyboard do not work
1. Keyboard
2. Keyboard Cable
3. System Board
Undetermined problems
This section provides instructions on how to find out the failing devices or adapters.
1. Turn off the computer.
2. Remove or disconnect the following components (if installed) one at a time.
a. External devices (modem, printer, or mouse)
b. Any adapters
c. Memory modules
d. Extended video memory
e. External Cache
f. External Cache RAM
g. Hard disk drive
h. Diskette drive
3. Turn on the computer to retest the system.
4. Repeat steps 1 through 3 until you find the failing device or adapter.
If all devices and adapters have been removed, and the problem continues, replace the system board. See
Chapter 5 “Hardware removal and installation” on page 41.
Diagnostics
Use diagnostic solutions to test hardware components and report operating-system-controlled settings that
interfere with the correct operation of your computer.
Basic procedure for resolving computer problems
Prerequisite
Before you start, read Chapter 1 “Important safety information” on page 1 and print the following
instructions.
1. Check that:
a. The cables for all connected devices are connected correctly and securely.
b. All components have been reassembled correctly.
c. All connected devices that require ac power are connected to properly grounded and working
electrical outlets.
Chapter 4. Service checkout and symptom-to-FRU index 37

Lenovo ThinkCentre M80q Specifications

General

Audio chip	Realtek ALC233VB
Audio system	High Definition Audio
Product type	Mini PC
Number of speakers	1
Motherboard chipset	Intel Q470
Password protection type	HDD, Power on, Supervisor
Volume	1 L
Product color	Black
Placement supported	Vertical
Cable lock slot type	Kensington
Processor cache	16 MB
Processor cores	8
Processor family	Intel® Core™ i7
Processor threads	16
Processor frequency	2 GHz
Processor cache type	Smart Cache
Configurable TDP-down	25 W
Processor manufacturer	Intel
Processor boost frequency	4.5 GHz
Configurable TDP-down frequency	1.3 GHz
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory channels	Dual-channel
Memory clock speed	2933 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	64 GB
Memory layout (slots x size)	1 x 16 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express 3.0
Storage media	SSD
SSD form factor	M.2
Optical drive type	No
Total storage capacity	512 GB
Operating system language	DEU, DUT, ENG, FRE, ITA
Operating system architecture	64-bit
Discrete graphics card model	Not available
On-board graphics card model	Intel® UHD Graphics 630
On-board graphics card family	Intel® UHD Graphics
Power supply	135 W
Antenna type	2x2
LAN controller	Intel® I219-LM
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Bluetooth version	5.1
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6 AX201
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
Certification	EPEAT Silver, ENERGY STAR 8.0, ErP Lot 3, TCO Certified 8.0, RoHS, MIL-STD-810H
Sustainability certificates	ENERGY STAR, TCO, EPEAT Silver, RoHS

Weight and Dimensions

Depth	183 mm
Width	179 mm
Height	31 mm
Weight	1250 g
