Lenovo ThinkVision T27hv-20 User Manual

Product overview
This section will provide information on adjusting monitor positions, setting user controls,
and using the cable lock slot.
Types of adjustments
Tilt
Please see the illustration below for an example of the tilt range.
-5°
0°
35°
Swivel
With the built-in pedestal, you can tilt and swivel the monitor for the most comfortable
viewing angle.
45°
45°
Height Adjustment
For height adjustment, user needs to press down or lift up the monitor.
135mm
1-3 T27hv-20 Flat Panel Monitor User’s Guide

Lenovo ThinkVision T27hv-20 Specifications

General

HD type	2K Ultra HD
Color depth	8 bit
Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Pixel density	109 ppi
Response time	6 ms
Backlight type	W-LED
Display surface	Matt
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Response time (fast)	4 ms
Viewable size, vertical	335.67 mm
sRGB coverage (typical)	99 %
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	596.74 mm
Display brightness (typical)	350 cd/m²
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	148 W
Power consumption (off)	0.3 W
Annual energy consumption	66.47 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Color name	Raven Black
Product color	Black
Market positioning	Gaming
Megapixel	2 MP
RMS rated power	6 W
Number of speakers	2
Package type	Box
Package depth	159 mm
Package width	860 mm
Package height	515 mm
Package weight	10550 g
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Height adjustment	135 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
USB Power Delivery up to	90 W
USB Type-A downstream ports quantity	4
Number of USB Type-C upstream ports quantity	1
Sustainability certificates	ENERGY STAR, EPEAT Silver, RoHS, TCO
Cables included	AC, USB Type-C to USB Type-C

Weight and Dimensions

Bezel width (side)	2 mm
Depth (with stand)	208 mm
Width (with stand)	613.6 mm
Height (with stand)	608.6 mm
Weight (with stand)	7350 g
Bezel width (bottom)	50.07 mm
Depth (without stand)	45.5 mm
Height (without stand)	412.6 mm
Weight (without stand)	4850 g
