Lenovo ThinkVision T27hv-20 User Manual

Service information
Customer responsibilities
The warranty does not apply to a product which has been damaged due to accident,
misuse, abuse, improper installation, usage not in accordance with product specications
and instructions, natural or personal disaster, or unauthorized alterations, repairs or
modications.
The following are examples of misuse or abuse and not covered by warranty:
• Images burned on to the screen of a CRT monitor. Burned image is preventable by
utilizing a moving screen saver or power management.
• Physical damage to covers, bezel, base and cables.
• Scratches or punctures on monitor screens.
Service parts
The following parts are for use by Lenovo service, or Lenovo authorized dealers to support
the customer warranty. Parts are for service use only. The table below shows information
for model (A20270QT0/ T27hv-20 / 62A9-GAR1-WW).
Table 3-3. List of service parts
FRU (Field
Replaceable Unit)
Part number
Description
Machine Type
Model (MTM)
colour
5D11A20411
T27hv-20 - 27 inch FRU
Monitor (HDMI)
62A9 Raven Black
5C11A20409 T27hv-20 DP cable 62A9 Raven Black
5C11A20410 T27hv-20 HDMI cable 62A9 Raven Black
5C11A20408
T27hv-20 USB Type C to
Type A cable
62A9 Raven Black
5C11A20406
T27hv-20 USB Type C to
Type C cable
62A9 Raven Black
5SE1A20407
T27hv-20 - FRU Base and
Stand
62A9 Raven Black
3-7 T27hv-20 Flat Panel Monitor User’s Guide

Lenovo ThinkVision T27hv-20 Specifications

General

HD type	2K Ultra HD
Color depth	8 bit
Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Pixel density	109 ppi
Response time	6 ms
Backlight type	W-LED
Display surface	Matt
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Response time (fast)	4 ms
Viewable size, vertical	335.67 mm
sRGB coverage (typical)	99 %
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	596.74 mm
Display brightness (typical)	350 cd/m²
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	148 W
Power consumption (off)	0.3 W
Annual energy consumption	66.47 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Color name	Raven Black
Product color	Black
Market positioning	Gaming
Megapixel	2 MP
RMS rated power	6 W
Number of speakers	2
Package type	Box
Package depth	159 mm
Package width	860 mm
Package height	515 mm
Package weight	10550 g
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Height adjustment	135 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
USB Power Delivery up to	90 W
USB Type-A downstream ports quantity	4
Number of USB Type-C upstream ports quantity	1
Sustainability certificates	ENERGY STAR, EPEAT Silver, RoHS, TCO
Cables included	AC, USB Type-C to USB Type-C

Weight and Dimensions

Bezel width (side)	2 mm
Depth (with stand)	208 mm
Width (with stand)	613.6 mm
Height (with stand)	608.6 mm
Weight (with stand)	7350 g
Bezel width (bottom)	50.07 mm
Depth (without stand)	45.5 mm
Height (without stand)	412.6 mm
Weight (without stand)	4850 g
