Lenovo ThinkVision T27hv-20 User Manual

Adjusting your monitor image
This section describes the user control features used to adjust your monitor image.
Using the direct access controls
The direct access controls can be used when the On Screen Display (OSD) is not displayed.
Table 2-1. Direct access controls
Icon Control Description
1
Microphone Mute
Use the Microphone Mute button to mute
microphone.
Return button
Return to the previous menu page or exit from the
previous function.
2
Audio Mute Use the Mute button to mute audio.
Increase/UP
UP browsing key
For increasing the value on adjustment bar/tune in
3
Input Source Switches the video input source
Decrease/Down
Down browsing key.
For decreasing the value on adjustment bar/tune in.
Press to move to next item.
Press and hold for 3 seconds to Enable/Disable smart
trafc light.
4
Menu
To access OSD menu.
Press to conrm selection.
Press and hold for 10 seconds will lock menu/un-lock
menu.
Press and hold for 3 seconds to Enable/Disable face
tracking function
Enter
Press to enter next level on main menu/sub menu
status or enter previous level on adjustment bar.
5
Volume up Press to control Speaker Volume up.
Volume down Press to control Speaker Volume down.
2-3 T27hv-20 Flat Panel Monitor User’s Guide

Lenovo ThinkVision T27hv-20 Specifications

General

HD type	2K Ultra HD
Color depth	8 bit
Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Pixel density	109 ppi
Response time	6 ms
Backlight type	W-LED
Display surface	Matt
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Response time (fast)	4 ms
Viewable size, vertical	335.67 mm
sRGB coverage (typical)	99 %
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	596.74 mm
Display brightness (typical)	350 cd/m²
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	148 W
Power consumption (off)	0.3 W
Annual energy consumption	66.47 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Color name	Raven Black
Product color	Black
Market positioning	Gaming
Megapixel	2 MP
RMS rated power	6 W
Number of speakers	2
Package type	Box
Package depth	159 mm
Package width	860 mm
Package height	515 mm
Package weight	10550 g
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Height adjustment	135 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
USB Power Delivery up to	90 W
USB Type-A downstream ports quantity	4
Number of USB Type-C upstream ports quantity	1
Sustainability certificates	ENERGY STAR, EPEAT Silver, RoHS, TCO
Cables included	AC, USB Type-C to USB Type-C

Weight and Dimensions

Bezel width (side)	2 mm
Depth (with stand)	208 mm
Width (with stand)	613.6 mm
Height (with stand)	608.6 mm
Weight (with stand)	7350 g
Bezel width (bottom)	50.07 mm
Depth (without stand)	45.5 mm
Height (without stand)	412.6 mm
Weight (without stand)	4850 g
