Lenovo ThinkVision T27hv-20 User Manual

Selecting a supported display mode
The display mode of the monitor uses is controlled by the computer. Therefore, refer to your
computer documentation on how to change display modes.
The image size, position and shape might be changed when the display mode changes. This
is normal and the image can be re-adjusted using automatic image setup and the image
controls. Unlike CRT monitors, which require a high refresh rate to minimize icker, LCD
or Flat Panel technology is inherently icker-free.
Note: If your system has previously been used with a CRT monitor and is currently
congured to a display mode outside the range of this monitor, you may need to reattach
the CRT monitor temporarily until you have re-congured the system; preferably to 2560 x
1440 at 60 Hz, which is a common display mode.
The display modes shown below have been optimized at the factory.
Table 2-3 Factory set display modes
Timing Refresh rate(Hz)
640x480 60 Hz
640x480 67 Hz
640x480 72 Hz
640x480 75 Hz
720x400 70 Hz
800x600 60 Hz
800x600 72 Hz
800x600 75 Hz
832x624 75 Hz
1024x768 60 Hz
1024x768 70 Hz
1024x768 75 Hz
1152x864 75 Hz
1280x1024 60 Hz
1280x1024 70 Hz
1280x1024 75 Hz
1440x900 60 Hz
1680x1050 60 Hz
1920x1080 60 Hz
1920x1200 60 Hz
2560x1440 60 Hz
2-9 T27hv-20 Flat Panel Monitor User’s Guide

Lenovo ThinkVision T27hv-20 Specifications

General

HD type	2K Ultra HD
Color depth	8 bit
Pixel pitch	0.2331 x 0.2331 mm
Screen shape	Flat
Pixel density	109 ppi
Response time	6 ms
Backlight type	W-LED
Display surface	Matt
Display diagonal	27 \
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Response time (fast)	4 ms
Viewable size, vertical	335.67 mm
sRGB coverage (typical)	99 %
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Viewable size, horizontal	596.74 mm
Display brightness (typical)	350 cd/m²
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	148 W
Power consumption (off)	0.3 W
Annual energy consumption	66.47 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Color name	Raven Black
Product color	Black
Market positioning	Gaming
Megapixel	2 MP
RMS rated power	6 W
Number of speakers	2
Package type	Box
Package depth	159 mm
Package width	860 mm
Package height	515 mm
Package weight	10550 g
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Height adjustment	135 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
USB Power Delivery up to	90 W
USB Type-A downstream ports quantity	4
Number of USB Type-C upstream ports quantity	1
Sustainability certificates	ENERGY STAR, EPEAT Silver, RoHS, TCO
Cables included	AC, USB Type-C to USB Type-C

Weight and Dimensions

Bezel width (side)	2 mm
Depth (with stand)	208 mm
Width (with stand)	613.6 mm
Height (with stand)	608.6 mm
Weight (with stand)	7350 g
Bezel width (bottom)	50.07 mm
Depth (without stand)	45.5 mm
Height (without stand)	412.6 mm
Weight (without stand)	4850 g
