Typical motor power P
r
[kW] 0.55 0.75 1.5 2.2
Three-phase asynchronous motor (4-pole) P
r
[hp] 0.75 1.0 2.0 3.0
8200 motec type E82MV551_4B E82MV751_4B E82MV152_4B E82MV222_4B
Mains voltage U
mains
[V] 3/PE AC 320 V - 0%...550 V + 0%; 45 Hz - 0%...65 Hz + 0%
Data for operation at 3/PE AC 500 V
Rated mains current I
mains
[A] 1.4 1.9 3.0 4.5
Output power U, V, W (at 8 kHz) S
r
[kVA] 1.3 1.7 2.7 3.9
Rated output 2 kHz
I
r
[A] 1.8 2.4 3.9 5.6
current at switching
4 kHz
frequency
8 kHz I
r
[A] 1.6 2.1 3.5 5.0
16 kHz
2)
I
r
[A] 1.1 1.4 2.3 3.2
Max. permissible output 2 kHz
I
max
[A] 2.4 3.2 5.2 7.6
current for 60 s
4 kHz
at switching frequency
1)
8 kHz I
max
[A] 2.4 3.2 5.2 7.6
16 kHz
2)
I
max
[A] 1.6 2.1 3.5 4.8
Output voltage U
M
[V] 3~ 0 ... U
mains
/0 ... 650 Hz
Power loss (operation at I
r
at 8 kHz) P
v
[W] 35 45 70 95
Dimensions HxBxT [mm] 202 x 156 x151 230 x 176 x 167
Weight m [kg] 2.8 4.1
Ratings at 500 V mains voltage
1)
Currents for periodic load change cycle: 1 min overcurrent duration at
I
max
and 2 min base load duration at 75% I
r
2)
To protect the inverter shutting down in the event of overtemperatures,
before the shutdown temperature is reached, the switching frequency
automatically drops to 4 kHz.
Standard controllers
8200 motec – Operation at rated power (normal operation)
