Instalación eléctrica

Esquema de conexiones



109

EDK94AZMP DE/EN/FR/ES/IT 8.0

Uso con i700

1 (BK)

2 (BK)

3 (BK)

PE (GN/YE)

F1...F3

X301

X100

X302

E70ACPSxxxx4x

T1 T2

E94AZMPxxxx

SSP94NF105 S2

Fig.6−2 Principio de conexión

E94AZRPxxxx Filtro anti−radiación

E70ACPSxxxx4x Módulo de alimentación CC i700

F1 ... F3 Fusibles

K1 Contactor de red
