6.4 Mounting steps
Use with 9400
Proceed as follows to connect the filter:
1. Connect the filter output cable (X302) to the installation backplane of the
power supply module.
2. Connect the mains cable to terminal X301.
3. Attach the supply−side PE conductor to the protective conductor screw
using a fork−type or a ring cable lug.
– The PE connection must comply with EN 61800−5−1.
4. Connect the thermal contact cable to T1 and T2 terminals.
– Integrate the thermal contact into the system monitoring in order that
the mains supply will be switched off in case of filter overheating.
Use with i700
How to connect the filter:
1. Connect filter output line (X302) to the power supply module.
– Cable ends (cable lugs) may be removed.
– Cable lengths may be shortened, if required.
– Wire end ferrules are not required.
2. Connect mains cable to terminal X301.
3. Mount PE conductor on the supply side to PE conductor screw using a
fork−type cable lug or ring cable lug.
– The PE connection must be designed in accordance with EN 61800−5−1.
