Technical data
Rated data
4
42
EDK94AZMP DE/EN/FR/ES/IT 8.0
4.2 Rated data
Mains Voltage Voltage range Frequency range
U
Lrated
[V] U
Lrated
[V] f [Hz]
3/PE AC 230 180 − 0 % ... 264 + 0 % 45 − 0 % ... 65 + 0 %
3/PE AC 400 320 − 0 % ... 440 + 0 % 45 − 0 % ... 65 + 0 %
3/PE AC 500 400 − 0 % ... 550 + 0 % 45 − 0 % ... 65 + 0 %
Voltage Freq. Current [A] Current [A]
Number
of phases
[V] [Hz] max. +45° C max. +55° C
E94AZMP0084 230/400/500 50/60 8/8/8 6/6/6 3
E94AZMP0294 230/400/500 50/60 29/29/29 21.8/21.8/21.8 3
E94AZMP0294
2)
400/480 50/60 24.5/24.5 15.3/15.3 3
Temperature in the control cabinet
2)
For i700 mounting: mains connection at the bottom, output at the top
Power loss Inductance Voltage drop
P
loss
[W] L [mH] DU [V]
E94AZMP0084 50 3.9 9.8
E94AZMP0294 110 0.7 6.4
Thermal contact
Design max. switching voltage max. switching current
U
Th
[V AC] I
Th
[A]
E94AZMP0084
NC contact, 150 °C
250 2.5
E94AZMP0294
