Elektrische Installation

Anschlussplan



EDK94AZMP DE/EN/FR/ES/IT 8.0

Verwendung mit i700

1 (BK)

2 (BK)

3 (BK)

PE (GN/YE)

F1...F3

X301

X100

X302

E70ACPSxxxx4x

T1 T2

E94AZMPxxxx

SSP94NF105 S2

Abb. 6−2 Schaltungsprinzip

E94AZRPxxxx Funk−Entstörfilter

E70ACPSxxxx4x DC Versorgungsmodul i700

F1 ... F3 Sicherungen

K1 Netzschütz
