System modules
AIF1_IO_AutomationInterface (node number 41)
Inputs_AIF1
13
259
EDBCSXA064 EN 3.2
13.2 AIF1_IO_AutomationInterface (node number 41)
13.2.1 Inputs_AIF1
This SB is used as an interface for input signals (e.g. setpoints/actual values) to the
attached fieldbus module (e.g. INTERBUS, PROFIBUS−DP).
The process image is
ƒ created in the cyclic task by means of a fixed set time interval of 10 ms.
ƒ created in an interval task within the time set for this task.
ƒ read at the beginning of the task and written at its end.
Please read the documentation for the connected fieldbus module.
