System modules
MCTRL_MotorControl (node number 131)
Manual field weakening
13
362
EDBCSXA064 EN 3.2
13.20.10
Manual field weakening
A manual field weakening can be achieved via
MCTRL_nFldWeak_a
.
ƒ
For a maximum excitation
MCTRL_nFldWeak_a
has to be activated by +100 %
(= 16384).
ƒ
If
MCTRL_nFldWeak_a
is not connected (free), the field weakening automatically is
+100 %.
Stop!
If the field is weakened manually (
MCTRL_nFldWeak_a
< 100 %), the drive
cannot produce the maximum torque.
