Lenze SMVector 13554876 EDBSV01 EN v21.0 15
Installation
3.1.4 NEMA 4X (IP65) Models with Disconnect Switch
b2
b
b1
a
a1
c
c1
s1
s2
s2
s1
Mounting Screws
4 x #8-32
10 lb-in
4 x M4
1.2 Nm
()
Type
a
in
(mm)
a1
in
(mm)
b
in
(mm)
b1
in
(mm)
b2
in
(mm)
c
in
(mm)
c1
in
(mm)
s1
in
(mm)
s2
in
(mm)
m
lb
(kg)
AA1
ESV371N01SM_; ESV371N02YM_;
ESV371N02SL_; ESV371N04TM_;
ESV371N04TL_; ESV371N06TM_;
ESV751N01SM_; ESV751N02YM_;
ESV751N02SL_; ESV751N04TM_;
ESV751N04TL_; ESV751N06TM_;
6.28
(160)
5.90
(150)
10.99
(279)
9.54
(242)
0.66
(17)
4.47
(114)
.86
(22)
2.00
(51)
2.00
(51)
4.7
(2.13)
AA2
ESV112N01SM_; ESV112N02YM_;
ESV112N02SL_; ESV112N04TM_;
ESV112N04TL_; ESV152N02YM_;
ESV152N02SL_; ESV152N04TM_;
ESV152N04TL_; ESV152N06TM_;
ESV222N04TM_; ESV222N04TL_;
ESV222N06TM_; ESV302N04TL_;
6.28
(160)
5.90
(150)
10.99
(279)
9.54
(242)
0.66
(17)
6.31
(160)
.86
(22)
2.00
(51)
2.00
(51)
7.9
(3.58)
AD1 ESV222N02SL_; ESV222N02YM_;
7.12
(181)
6.74
(171)
10.99
(279)
9.54
(242)
0.66
(17)
6.77
(172)
.86
(22)
2.00
(51)
2.00
(51)
9.0
(4.08)
AB1
ESV552N02TM~; ESV752N02TM~
ESV752N04TM~; ESV752N06TM~;
ESV752N04TL~
8.04
(204)
7.56
(192)
13.00
(330)
11.04
(280)
0.92
(23)
8.00
(203)
.86
(22)
4.00
(102)
4.00
(102)
13.9
(6.32)
AC1
ESV402N02TM_; ESV402N04TM_;
ESV552N04TM_; ESV402N06TM_;
ESV552N06TM_; ESV402N04TL_;
ESV552N04TL_
8.96
(228)
8.48
(215)
13.00
(330)
11.04
(280)
0.92
(23)
8.04
204)
.86
(22)
4.00
(102)
4.00
(102)
14.7
(6.66)
AE1
ESV113N04TM~; ESV153N04TM~,
ESV113N06TM~; ESV153N06TM~
9.42
(240)
8.94
(228)
14.50
(368)
12.54
(319)
0.92
(24)
9.45
(241)
0.73
(19)
4.00
(102)
4.00
(102)
23.0
(10.4)
AF1
ESV113N02TM~; ESV153N02TM~
ESV113N04TL~; ESV153N04TL~
ESV183N04TL~; ESV223N04TL~
ESV183N04TM~; ESV223N04TM~
ESV183N06TM~; ESV223N06TM~
9.42
(240)
8.94
(228)
18.5
(470)
16.54
(420)
0.92
(24)
9.45
(241)
0.73
(19)
4.00
(102)
4.00
(102)
28.5
(12.9)
_ = Last digit of part number: C = N4X Indoor (convection cooled) ~ = Last digit of part number: D = N4X Indoor (fan cooled)
Conduit Hole Dimensions Type
N
in (mm)
P
in (mm)
Q
in (mm)
S
in (mm)
S1
in (mm)
QQ
P
N
S
S
S1
P
Q
Q
N
AA1 3.14 (80) 2.33 (59) 1.50 (38) .88 (22) .87 (22)
AA2 3.14 (80) 4.18 (106) 1.50 (38) .88 (22) .87 (22)
AD1 3.56 (90) 4.63 (118) 1.50 (38) .88 (22) .87 (22)
AB1 4.02 (102) 5.00 (127) 1.85 (47) 1.06 (27) 1.06 (27)
AC1 4.48 (114) 5.00 (127) 1.85 (47) 1.06 (27) 1.06 (27)
AE1 4.71 (120) 5.70 (145) 2.00 (51) 1.375 (35) 1.125 (28)
AF1 4.71 (120) 5.70 (145) 2.00 (51) 1.375 (35) 1.125 (28)
