A.1 Permissible Cable Lengths
NOTE
This table is intended as a reference guideline only; application results may vary. The values in this
table are based on testing with commonly available low-capacitance shielded cable and commonly
available AC induction motors. Testing is conducted at worst case speeds and loads.
ThetablehereinliststhepermissiblecablelengthsforusewithanSMVinverterwithaninternalEMClter.
Maximum Permissible Cable Lengths (Meters) for SMV Model with Internal EMC Filters
Mains Model 4 kHz Carrier
(P166 = 0)
6 kHz Carrier
(P166 = 1)
8 kHz Carrier
(P166 = 2)
10 kHz Carrier
(P166 = 3)
Class A Class B Class A Class B Class A Class B Class A Class B
240 V, 1-phase
(2/PE)
ESV251GG2SFG 38 12 35 10 33 5 30 N/A
ESV371GG2SFG 38 12 35 10 33 5 30 N/A
ESV751GG2SFG 38 12 35 10 33 5 30 N/A
ESV112GG2SFG 38 12 35 10 33 5 30 N/A
ESV152GG2SFG 38 12 35 10 33 5 30 N/A
ESV222GG2SFG 38 12 35 10 33 5 30 N/A
400/480 V,3-phase
(3/PE)
ESV371GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV751GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV112GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV152GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV222GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV302GG4TFG 30 4 25 2 20 N/A 10 N/A
ESV402GG4TFG 54 5 48 3 42 2 N/A N/A
ESV552GG4TFG 54 5 48 3 42 2 N/A N/A
ESV752GG4TFG 54 5 48 3 42 2 N/A N/A
Appendix A
NOTE: The “GG” and “G” symbols are place holders in the Model part number that contain different information
dependingonthespeciccongurationofthemodel.RefertotheSMVTypeNumberDesignationtableinsection
2.2 for more information.
