Inverter mains connecon 400 V, Self-venlated motors
2 kW
Inverter operaon Geared motor Number of
stages
M
2
n
2
c M
2, max
n
2, th
J i g500- m850 z m
Nm rpm Nm rpm kgcm² kg
22.0 810 4.8 67.0 716 8.244 4.889 B240 120S40 2 16
24.0 764 2.1 69.0 590 7.293 5.185 B110 120S40 2 11
27.0 664 1.9 72.0 498 7.205 5.963 B110 120S40 2 11
29.0 633 4.0 86.0 591 7.651 6.257 B240 120S40 2 16
31.0 577 5.6 94.0 526 8.982 6.860 B450 120S40 3 19
31.0 575 4.1 95.0 422 8.174 6.883 B240 120S40 2 16
32.0 557 1.7 77.0 445 6.978 7.111 B110 120S40 2 11
36.0 507 3.8 108 366 8.013 7.817 B240 120S40 2 16
37.0 484 1.6 81.0 371 6.931 8.178 B110 120S40 2 11
42.0 435 1.5 84.0 378 6.823 9.101 B110 120S40 2 11
43.0 420 3.2 130 344 7.554 9.440 B240 120S40 2 16
43.0 416 5.6 131 379 10.261 9.520 B820 120S40 3 42
47.0 383 5.9 142 301 9.560 10.328 B450 120S40 3 19
48.0 378 1.4 89.0 316 6.795 10.466 B110 120S40 2 11
49.0 369 3.0 148 299 7.468 10.720 B240 120S40 2 16
52.0 346 1.3 90.0 293 6.755 11.449 B110 120S40 2 11
55.0 328 2.7 166 286 7.229 12.081 B240 120S40 2 16
55.0 326 4.8 167 317 9.020 12.143 B820 120S40 3 42
58.0 312 1.1 90.0 293 6.693 12.698 B110 120S40 2 11
58.0 310 5.0 176 277 8.368 12.775 B450 120S40 3 19
61.0 296 5.9 184 264 10.201 13.370 B820 120S40 3 42
61.0 296 5.9 184 264 9.006 13.369 B600 120S40 3 37
63.0 289 2.5 189 248 7.177 13.719 B240 120S40 2 16
65.0 280 4.7 195 247 8.291 14.165 B450 120S40 3 19
67.0 271 5.6 201 247 9.704 14.626 B820 120S40 3 42
68.0 264 2.4 207 233 7.086 15.008 B240 120S40 2 16
75.0 242 4.2 225 228 7.727 16.349 B450 120S40 3 19
75.0 242 5.6 225 221 9.596 16.352 B820 120S40 3 42
77.0 235 2.3 232 235 6.947 16.857 B240 120S40 2 16
82.0 221 4.0 246 214 7.546 17.885 B450 120S40 3 19
85.0 212 4.8 257 206 8.678 18.655 B820 120S40 3 42
86.0 210 5.1 260 182 8.788 18.851 B600 120S40 3 37
87.0 207 2.0 240 207 6.920 19.143 B240 120S40 2 16
90.0 200 3.6 273 190 7.506 19.831 B450 120S40 3 19
94.0 192 4.6 284 169 8.523 20.622 B600 120S40 3 37
94.0 192 1.8 240 192 6.840 20.650 B240 120S40 2 16
95.0 190 4.8 287 184 8.611 20.857 B820 120S40 3 42
104 174 3.1 314 174 7.202 22.813 B450 120S40 3 19
104 173 4.1 315 173 8.097 22.853 B820 120S40 3 42
104 173 4.1 315 173 7.688 22.852 B600 120S40 3 37
107 169 1.6 240 169 6.822 23.450 B240 120S40 2 16
115 157 2.8 348 157 7.178 25.294 B450 120S40 3 19
116 155 4.1 352 155 8.053 25.550 B820 120S40 3 42
123 147 1.4 240 147 6.711 26.878 B240 120S40 2 16
127 142 2.6 385 142 7.010 27.945 B450 120S40 3 19
133 136 5.9 402 122 10.794 29.206 B1500 120S40 3 72
136 133 3.2 410 133 7.220 29.744 B600 120S40 3 37
136 133 3.3 410 133 7.409 29.745 B820 120S40 3 42
139 130 1.3 240 130 6.700 30.522 B240 120S40 2 16
141 128 2.3 427 128 6.994 30.985 B450 120S40 3 19
Technical data
Selecon tables
Inverter mains connecon 400 V, Self-venlated motors
65
