Lenze g500-B110 User Manual

Features
The following gure provides an overview of the elements and connecons on the product.
Their posion, size and appearance may vary.
Torque plate mounting
Output flange
Output shaft
Torque plate mounting
Housing type
(depending on the
mounting position)
Oil drain plug
(depending on the mounting position)
(depending on the mounting position)
Remove oil control plug
Oil filler plug
(depending on the mounting position)
Ventilation
Temperature monitoring
Spring-applied brake
Feedback
Motor connection
Cooling
Product informaon
