Basic dimensions
g500-B110, 2-stag
e
Gearbox v
ersion: Hollow
sha
with f
oot (HAR/HBR/HAK)
Motor
m850-
S120/S3960
S120/M3960
T
otal length
L
mm
382
420
Motor length
LB
mm
182
220
Length of motor
opons
Δ L
mm
46
46
Motor diameter
AC
mm
121
121
Motor/c
onnecon
distance
AD
mm
102
102
T
echnical da
ta
Dimensions
Basic dimensions
91
90
92
