Product descripon
When used in combinaon with servo motors, our bevel gearboxes form a compact, powerful
and dynamic drive unit. Numerous opons at the input and output end provide for the drive
to be exactly adapted to your applicaon.
The ecient bevel gearboxes are characterized by high permissible radial forces, closely
stepped speed reducon raos and a low backlash . They are available in a 2-, 3- and 4-stage
design with a torque of up to 4300 Nm and a rao of up to i= 3167.
Designs
•
High-ecient right-angle gearbox in a compact design for space-saving installaon
•
Standardised sha and ange dimensions for an easy machine integraon
•
Low backlash and high torsional sness provide for exact results in posioning
applicaons
Synchronous servo motor m850 as basis for geared motor
In a power range of 2.0 to 9.2 kW, Lenze oers servo motors with an easily scalable modular
design.
The drives are designed for the open-loop or closed-loop controlled servo inverter operaon.
Medium dynamics and easy controllability via a favourable mass inera rao of the load to the
motor characterise these motors.
Customer benet
•
Easy controllability by an advantageous rao of the mass inera of the load and that of the
motor
•
High overload capacity of the motors
•
Easy assembly and easy servicing thanks to connectors with bayonet catch and rotatable
connector boxes
•
Reduced cabling thanks to one-cable technology in connecon with digital absolute value
encoders
•
High eciency
•
Space-saving thanks to compact direct aachment to Lenze gearboxes
•
Can be used universally for a wide range of machine tasks due to the market-oriented
modular system
m850-S120/L3960 synchronous servo motor - g500-B450 bevel gearbox m850-S120/L3960 synchronous servo motor - g500-B450 bevel gearbox
with One Cable Technology (OCT) in connecon with a digital absolute
value encoder
