Weights
Basic weights
The basic weights are listed in the selecon tables.
Weights with lubricant for mounng posion M1, all data approximate values.
The exact values can be found in the delivery documents
4Selecon tables ^ 55
Observe 4Addional weights ^ 120!
Addional weights
Add the individual addional weights to the basic weight depending on the
design.
Gearbox
Gearbox g500-H45 g500-H100 g500-H140 g500-H210 g500-H320 g500-H450
Foot m kg 0.1 0.1 0.2 0.1 0.1 0.2
Flange m kg 0.3 0.4 0.6 0.6 0.8 0.9
Flange (VCP) m kg 2.0 3.9 3.9 4.1 6.1
Gearbox g500-H600 g500-H850 g500-H1500 g500-H3000
Foot m kg 2.0 2.8 4.3 5.8
Flange m kg 4.3 7.6 8.3 20
Flange (VCP) m kg
Motors
Motor MF☐MA☐☐
063-32 071-32 080-32 090-32 100-12 112-22 132-12
063-42 071-42 080-42 100-32 132--22
132-32
Brake
06 m kg 0.9 0.9
08 m kg 1.5 1.5 1.5
10 m kg 2.6 2.6 2.6
12 m kg 4.2 4.2
14 m kg 5.8 5.8
16 m kg 8.7
Manual release lever m kg 0.1 0.1 0.2 0.2 0.2 0.4 0.5
Blower m kg 2.0 2.1 2.3 2.7 3.0 3.1 4.2
Technical data
Weights
Basic weights
120
