Connecon via terminal box
Posion of the connecons
1
2
Posion Meaning Note
1 Power connecon
Brake connecon
PE connecon
Feedback connecon
Connecon of temperature monitoring
For the terminal box "KK1", the posion of the cable connecons
"L", "R" or "E" must be specied.
2 Blower connecon When ordering, specify the mounng posion of the terminal
box:
•
Shown here: "T"
•
"L", "R" or "B"
If required, the terminal box can be rotated step by step by 90 °
aer loosening the screws in the terminal box.
Power connecon
Bridge arrangement
Y/Δ circuit
W2
U2
V2
U1
V1
W1
L1
L2
L3
W2
U1
U2
V1
V2
W1
L1
L2
L3
Terminal box, power
Contact Name Meaning
PE PE PE conductor
U1 L1
Motor winding phaseV1 L2
W1 L3
DC brake connecon
Terminal box, DC brake
Contact Name Meaning
BD1 + Brake +
BD2 - Brake -
Product extensions
Motor connecon
Connecon via terminal box
131
