Lenze g500-H Series User Manual

Motor data
Rated data
Rated data 120 Hz
Motor MF☐MA☐☐
063-32 063-42 071-32 071-42 080-32
Rated power P
rated
kW 0.55 0.75 1.1 1.5 2.2
Rated speed n
rated
rpm 3440 3400 3490 3450 3500
Max. speed n
max
rpm 4500 4500 4500 4500 4500
Max. torque M
max
Nm 6.00 8.00 12.0 16.0 24.0
Rated voltage
Delta V
N, Δ
V 200 210 200 205 200
Star V
N, Y
V 345 370 345 360 345
Rated current
Delta I
N, Δ
A 3.20 4.00 5.50 6.80 9.10
Star I
N, Y
A 1.80 2.30 3.20 3.90 5.30
Rated torque M
rated
Nm 1.53 2.11 3.01 4.15 6.00
Power factor cos ϕ 0.68 0.69 0.77 0.8 0.86
Eciency
at 75 % P
rated
η 0.750 0.796 0.814 0.828 0.843
at 100 % P
rated
η 0.750 0.796 0.814 0.828 0.843
Moment of inera J kgcm² 3.70 3.70 12.8 12.8 28.0
Weight m kg 4.40 4.40 6.40 6.40 11.0
Motor MF☐MA☐☐
080-42 090-32 100-12 100-32 112-22
Rated power P
rated
kW 3 4 5.5 7.5 11
Rated speed n
rated
rpm 3480 3480 3525 3515 3530
Max. speed n
max
rpm 4500 4500 4500 4500 4500
Max. torque M
max
Nm 32.0 44.0 60.0 80.0 120
Rated voltage
Delta V
N, Δ
V 210 - - - -
Star V
N, Y
V 370 370 340 375 370
Rated current
Delta I
N, Δ
A 11.4 - - - -
Star I
N, Y
A 6.60 8.50 12.9 15.9 23.5
Rated torque M
rated
Nm 8.20 10.9 14.9 20.3 29.7
Power factor cos ϕ 0.86 0.85 0.81 0.81 0.78
Eciency
at 75 % P
rated
η 0.855 0.870 0.879 0.889 0.898
at 100 % P
rated
η 0.855 0.866 0.877 0.887 0.898
Moment of inera J kgcm² 28.0 32.0 61.0 61.0 107
Weight m kg 11.0 18.0 26.5 26.5 38.0
Motor data
Rated data
Rated data 120 Hz
163
