Lenze g500-H Project Planning

Data overview
In order to calculate the exact rao, the number of teeth z
g
(driven) can be divided by the
number of teeth z
t
(driving). These are rounded values.
The rated torque can be gathered from the last digits of the product name e.g.
g500-B110 (110 Nm).
g500-H45, 2-stage
Max. output torque Rao Number of teeth Backlash
Standard
M
2,max
i z
g
z
t
± 20 %
Nm '
18 2.597 896 345 41
19 3.413 256 75 39
21 4.368 1376 315 38
27 5.312 1344 253 28
29 5.965 686 115 28
30 6.982 384 55 27
32 7.840 196 25 27
33 8.935 688 77 27
35 10.033 301 30 26
35 11.429 80 7 26
38 12.833 77 6 26
39 14.836 816 55 26
41 16.660 833 50 25
42 19.013 1464 77 26
44 21.350 427 20 25
45 24.595 2976 121 25
45 27.618 1519 55 25
45 32.000 32 1 26
45 35.933 539 15 25
45 41.455 456 11 25
45 46.550 931 20 25
45 52.909 582 11 25
45 59.413 4753 80 25
Technical data
Data overview
41
