Lenze g500-H Project Planning

Inverter mains connecon 400 V, Self-venlated motors
2 kW
Inverter operaon Geared motor Number of
stages
M
2
n
2
c M
2, max
n
2, th
J i g500- m850 z m
Nm rpm Nm rpm kgcm² kg
15.0 1212 3.9 46.0 1056 7.402 3.267 H140 120S40 2 11
16.0 1181 2.9 47.0 970 7.025 3.354 H100 120S40 2 10
16.0 1169 5.8 48.0 915 8.030 3.389 H210 120S40 2 13
21.0 884 3.3 63.0 828 7.036 4.480 H140 120S40 2 11
21.0 861 2.4 65.0 766 6.835 4.600 H100 120S40 2 10
22.0 852 4.8 65.0 754 7.477 4.648 H210 120S40 2 13
22.0 852 5.6 65.0 777 7.315 4.648 H320 120S40 2 14
24.0 767 2.3 73.0 600 6.929 5.167 H100 120S40 2 10
26.0 709 4.4 79.0 528 7.743 5.583 H210 120S40 2 13
27.0 691 2.8 81.0 691 6.859 5.733 H140 120S40 2 11
27.0 691 5.9 81.0 616 9.366 5.733 H600 120S40 2 29
27.0 673 2.1 81.0 673 6.736 5.887 H100 120S40 2 10
28.0 655 5.9 85.0 584 8.731 6.045 H450 120S40 2 18
28.0 651 5.8 86.0 510 8.155 6.083 H320 120S40 2 14
29.0 634 3.9 88.0 461 7.684 6.250 H210 120S40 2 13
29.0 631 2.6 88.0 631 6.809 6.272 H140 120S40 2 11
30.0 615 2.0 83.0 615 6.707 6.440 H100 120S40 2 10
31.0 599 5.6 93.0 546 8.476 6.613 H450 120S40 2 18
32.0 573 4.9 97.0 435 8.009 6.910 H320 120S40 2 14
33.0 559 1.9 86.0 468 6.785 7.086 H100 120S40 2 10
34.0 545 2.3 102 427 7.005 7.269 H140 120S40 2 11
36.0 517 3.5 108 431 7.325 7.657 H210 120S40 2 13
37.0 495 2.3 113 495 6.711 8.000 H140 120S40 2 11
38.0 482 1.7 92.0 482 6.648 8.214 H100 120S40 2 10
39.0 475 4.6 117 418 7.544 8.343 H320 120S40 2 14
40.0 462 3.1 121 376 7.293 8.571 H210 120S40 2 13
42.0 439 2.0 117 377 6.842 9.029 H140 120S40 2 11
42.0 437 1.6 96.0 402 6.705 9.068 H100 120S40 2 10
44.0 418 3.9 133 356 7.466 9.477 H320 120S40 2 14
46.0 404 2.0 125 404 6.655 9.800 H140 120S40 2 11
46.0 404 2.9 138 356 7.089 9.799 H210 120S40 2 13
46.0 397 5.9 140 354 8.309 9.965 H450 120S40 2 18
47.0 394 1.5 99.0 394 6.613 10.063 H100 120S40 2 10
50.0 371 3.9 150 345 7.223 10.677 H320 120S40 2 14
50.0 369 2.7 151 335 7.013 10.720 H210 120S40 2 13
52.0 352 5.5 158 310 8.237 11.262 H450 120S40 2 18
53.0 350 5.9 159 312 8.569 11.330 H600 120S40 2 29
53.0 349 1.4 100 307 6.675 11.360 H100 120S40 2 10
54.0 343 1.7 128 323 6.740 11.554 H140 120S40 2 11
54.0 339 3.6 164 323 7.125 11.680 H320 120S40 2 14
56.0 330 2.4 169 292 6.997 12.000 H210 120S40 2 13
56.0 327 3.3 171 294 7.176 12.128 H320 120S40 2 14
57.0 321 5.2 173 289 8.063 12.320 H450 120S40 2 18
58.0 320 5.6 174 291 8.341 12.395 H600 120S40 2 29
59.0 313 1.6 132 299 6.710 12.640 H140 120S40 2 11
59.0 313 1.2 100 303 6.632 12.653 H100 120S40 2 10
62.0 299 3.1 187 276 7.086 13.268 H320 120S40 2 14
64.0 290 2.3 192 290 6.875 13.673 H210 120S40 2 13
65.0 285 4.8 196 277 7.706 13.905 H450 120S40 2 18
65.0 285 5.6 196 260 8.247 13.920 H600 120S40 2 29
Technical data
Selecon tables
Inverter mains connecon 400 V, Self-venlated motors
65
