Lenze IE2 g500-H User Manual

Connecon of temperature monitoring
Terminal box, temperature monitoring
Contact Name Meaning
TB1
Temperature monitoring: TCO
TB2
1TP1 PTC150 thermistor
2TP1 PTC130 thermistor
R1 + Temperature sensor PT1000 +
R2 - Temperature sensor PT1000 -
1TP2 PTC150 thermistor
2TP2 PTC130 thermistor
Connecon of temperature monitoring
Blower connecon
Terminal box, 1-phase separate fan
Contact Name Meaning
PE PE PE conductor
U1 L1
Mains
U2 N
Terminal box, 3-phase separate fan
Contact Name Meaning
PE PE PE conductor
U1 L1
Mains conneconV1 L2
W1 L3
Product extensions
Motor connecon
Connecon via terminal box
133
