Page #27 background imageLoading...
Page #27 background image
25
Commissioning
WORD0 - C0135 control word
Bit h66 / h76 setting = 4
0
JOG1, JOG2, JOG3
0 = C46 active
1 = JOG1 (C37) active
2 = JOG2 (C38) active
3 = JOG3 (C39) active
1
2
Direction of rotation
0 = CW (forward)
1 = CCW (reverse)
3
Quick stop
0 = Quick stop not active
1 = Quick stop active
4 reserved
5 reserved
6 reserved
7 reserved
8 reserved
9
Controller inhibit
0 = No controller inhibit
1 = Controller inhibit
10
reserved
11
TRIP reset
TRIP reset on transition from 0 to 1
12 reserved
13 reserved
14
DC brake
0 = DC brake not active
1 = DC brake active
15 reserved
WORD1
Speed signed scaled +/- 16384 == C11
(max frequency)
Example 1: Requested setpoint = CW at
34.5 Hz and C11 = 50.0Hz:
Setpoint = roundup(34.5 * 16384/50) = 11305
= 0x2C29
Example 2: Requested setpoint = CCW at
44.5 Hz and C11 = 50.0Hz:
= - roundup(44.5 * 16384/50) = -14582 = 0xC70A
Note: Setpoint sign overrides Bit 2 in WORD0
WORD2
Digital outputs (RELAY + E3)
Bit 0 - RELAY - (if C08 set to selection 9)
Bit 1 - E3 (if CE3 set to selection 30)
WORD3
Analog output 0-1000 -- corresponds to 0-10V
ex. 600 -> 6.0V (if c11 set to selection 5)
