Technical data
(1) For rated mains voltage and carrier frequencies 4, 6, and 8 kHz
(2) For rated mains voltage and carrier frequency 10 kHz
(3) Maximum current is a function of setting C90 (input voltage selection)
2.2 Ratings
Type
Power
[kW]
Mains
Output Current
(3)
Voltage, frequency
Current
[A]
(3)
I
N
I
max
for 60 s
[A]
(1)
[A]
(2)
[A]
(1)
[A]
(2)
1~ 3~ 3~ 3~ 3~ 3~
ESMD371C2YXA 0.37
1/N/PE 230 V OR
3/PE 230 V
(180 V -0%…264 V +0%)
50/60 Hz
(48 Hz -0%…62 Hz +0%)
4.7 2.7 2.2 2.0 3.3 3.0
ESMD751C2YXA 0.75 8.4 4.8 4.0 3.7 6.0 5.6
ESMD112C2YXA 1.1 12.0 6.9 6.0 5.5 9.0 8.3
ESMD152C2YXA 1.5 12.9 7.9 6.8 6.3 10.2 9.5
ESMD222C2YXA 2.2 17.1 10.8 9.6 8.8 14.4 13.2
ESMD302C2TXA 3.0
3/PE 230 V
(180 V -0%…264 V +0%)
50/60 Hz
(48 Hz -0%…62 Hz +0%)
13.5 12.0 11.0 18.0 16.5
ESMD402C2TXA 4.0 17.1 15.2 14.0 23 21
ESMD552C2TXA 5.5 25 22 20 33 30
ESMD752C2TXA 7.5 32 28 26 42 39
ESMD113C2TXA 11 48 42 39 63 58
ESMD153C2TXA 15 59 54 50 81 75
400V 480V 400V 480V 400V 480V 400V 480V 400V 480V
ESMD371C4TXA 0.37
3/PE 400/480 V
(320 V -0%…528 V +0%)
50/60 Hz
(48 Hz -0%…62 Hz +0%)
1.6 1.4 1.3 1.1 1.2 1.0 2.0 1.7 1.8 1.5
ESMD751C4TXA 0.75 3.0 2.5 2.5 2.1 2.3 1.9 3.8 3.2 3.5 2.9
ESMD112C4TXA 1.1 4.3 3.6 3.6 3.0 3.3 2.8 5.4 4.5 5.0 4.2
ESMD152C4TXA 1.5 4.8 4.0 4.1 3.4 3.8 3.1 6.2 5.1 5.7 4.7
ESMD222C4TXA 2.2 6.4 5.4 5.8 4.8 5.3 4.4 8.7 7.2 8.0 6.6
ESMD302C4TXA 3.0 8.3 7.0 7.6 6.3 7.0 5.8 11.4 9.5 10.5 8.7
ESMD402C4TXA 4.0 10.6 8.8 9.4 7.8 8.6 7.2 14.1 11.7 12.9 10.8
ESMD552C4TXA 5.5 14.2 12.4 12.6 11.0 11.6 10.1 18.9 16.5 17.4 15.2
ESMD752C4TXA 7.5 18.1 15.8 16.1 14.0 14.8 12.9 24 21 22 19.4
ESMD113C4TXA 11 27 24 24 21 22 19.3 36 32 34 29
ESMD153C4TXA 15 35 31 31 27 29 25 47 41 43 37
ESMD183C4TXA 18.5 44 38 39 34 36 31 59 51 54 47
ESMD223C4TXA 22 52 45 46 40 42 37 69 60 64 55
