Lexmark E352DN Service Manual

Parts catalog 7-7
4512-420, -430
Assembly 3: Frame
Asm-
Index
Part
number
Units/
mach
Units/
FRU
Description
3–1 40X2834 1 Media exit guide assembly
2 40X2822 1 Transfer roll, bearings, gear, spring (CBM)
3 40X2858 1 1 Legal extender dust cover
4 40X2850 N/A
4
4
4
2
2
Screws, miscellaneous
TP2NCX3X6PF-Ni
TP2C-4.0+8PF-Ni
M3.0*0.5+6PF-Ni
M3.0*0.5+4PF-Ni
M3.5*0.6+6P-Ni
5 40X2853 1 1 ACM drive shaft assembly
6 40X2841 1 1 Complete duplex assembly
7 56P1820 2 Paper feed, ACM tires (RO)
8 40X2838 1 1 Media (ACM) drive assembly
9 40X2857 1 1 Upper front frame assembly
10 40X2830 1 1 Manual feed clutch CBM
11 40X2831 1 1 Media feed ACM clutch CBM
12 40X2832 1 1 Media level indicator CBM
13 40X2825 1 1 Developer drive/access door link
14 40X2829 1 1 Developer drive coupling assembly
15 40X2821 1 1 Duplex drive gear CBM
NS 40X2847 1 1 110 V maintenance kit
NS 40X2848 1 1 220 V maintenance kit
NS 40X2849 1 1 100 V maintenance kit
Note: Kit contains the following:
Fuser (40X2800, 40X2801, or 40X2802)
Exit guide (40X2834)
Tray 1 ACM feed tires (56P1820)
Transfer roll CBM (40X2822)
NS 7377298 1 Field location package assembly
NS 40X2817 1 2 Tray 2 paper feed tire

Lexmark E352DN Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 2400 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound pressure level (printing)	52 dB
Total input capacity	250 sheets
Maximum input capacity	800 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	80 gsm
Paper tray media types	Envelopes, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	TCP/IP IPv4, AppleTalk, TCP/IP IPv6
Compatible operating systems	Mac OS X Mac OS 9.x Citrix MetaFrame Linux Microsoft Windows 2000, NT, Me, XP, Server 2003, 98, Vista Novell UNIX
Maximum duty cycle	80000 pages per month
Sustainability certificates	ENERGY STAR
Operating altitude	0 - 2500 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Certification	FCC Class B, UL 60950-1, U.S. FDA, IEC 320-1, CSA, ICES Class B, CE Class B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick Class B, CCC Class B, BSMI Class B, MIC, EK Mark, PSB

Weight and Dimensions

Dimensions (WxDxH)	396 x 359 x 259.5 mm
