Page #33 background imageLoading...
Page #33 background image
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
LAN
2012/06/21
21
NC4_S7LRM
EPHY_RN
EPHY_TN
EPHY_TP
JK2100
XRJV-01V-0-D12-080
ETHERNET_XMULTIPLE
1
2
3
4
5
6
7
8
9
9
+2.5V_Normal
EPHY_RP
C2104
0.01uF
50V
ETHERNET
L2101
BLM18PG121SN1D
ETHERNET
R2101
49.9
ETHERNET
R2102
49.9
ETHERNET
C2101
0.1uF
ETHERNET
R2104
49.9
ETHERNET
C2102
0.1uF
ETHERNET
R2103
49.9
ETHERNET
JK2100-*1
RJ45VT-01SN002
ETHERNET_XML_EMI
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
ETHERNET
* H/W option : ETHERNET
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
