Standard Repair Process Detail Technical Manual
Inverter B+ 24V measuring method
A. Video error_No video/Normal audio
A2
Established
date
Revised
date
Error
symptom
Content
LCD TV
2012. 11 .17
Measure LED+ applying to LED Back Light from Power Board.
Output LED+ from Power Board -> supply to LED B/L.
Check Pin contacting statement and connection statement.
<LPB MODELS>
Copyright ⓒ 2012 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
