PTC INSTALLER MENU
xxLT570H
CPU - CTV
000 INSTALLER SEQ 000
UPN 000-000-000-000 ASIC D279
PTC V#.##.### CPU V#.##.##.##
Custom Master TV Setup (Cont.)
Custom Master TV Setup Procedure
1. Turn ON the TV.
The next step depends on whether the EZ-Manager Wizard appears
on the screen when you turn ON the TV:
• If the wizard is displayed, the TV is in the required factory default state.
Exit the wizard, and then continue with step 2.
• If the wizard is not displayed, restore the TV to a factory default
condition before continuing with this procedure. See Reference
section, “Restoring Factory Defaults on the TV(s),” as necessary,
for further information.
2. Set Installer Menu items.
This step provides specic instruction only on the Installer Menu items
that should be set on a Master TV. Refer to pages 25 to 35 for detailed
information on all Installer Menu items.
a) Use the Installer Remote to access the Installer Menu (see
“Accessing the Installer Menu” on page 25 for further information).
b) Set Installer Menu item 003 BAND/AFC, as appropriate.
• Broadcast: Set to 0. • HRC: Set to 2.
• Cable: Set to 1 (default). • IRC: Set to 3.
c) Set any other Installer Menu items that affect your TV programming
network to the required conguration. For example, enable/disable
Aux inputs, set a Start Channel, etc.
d) After you have adjusted all Installer Menu item settings as required,
and if you do not need to congure any IP Environment settings (see
note below), press OK once on the Installer Remote to save your
changes; then, press OK again to exit the menu.
Note: If you intend to congure settings in the IP Environment Menu,
which is accessible from the Installer Menu, you can proceed directly
to step 3. All Installer Menu settings will be saved automatically when
you access the IP Environment Menu.
3. Congure IP Environment settings.
Note: You cannot return directly to the Installer Menu from the IP
Environment Menu; thus, you may wish to set all Installer Menu items
as needed before you access the IP Environment Menu. Otherwise,
you will need to reaccess the Installer Menu to set additional items.
Navigate to Installer Menu item 119 DATA CHANNEL, and press
2-5-3 + MENU SETTINGS to launch the IP Environment Menu. Then,
complete network conguration as required. See “IP Environment
Setup” on pages 51 to 55 for further information.
(Continued on next page)
Typical Installer Menu
Adjust the value for this
Installer Menu item, as required.
003 BAND/AFC 001

LG 32LT570H Specifications

General

Screen Size	32 inches
Resolution	1366 x 768
Display Type	LCD
Smart TV	Yes
HDMI Ports	2
USB Ports	1
Ethernet Port	Yes
LCD Backlight Technology	Direct LED
Refresh Rate	60Hz
Sound Output	20W
Audio Output	10W x 2
Wi-Fi	Yes (802.11ac)
