Reference: Auto Input(s) Sensing Feature
This section provides detailed settings information for Installer Menu item 042 AUTO INPUTS. To disable
auto-sensing for all available Aux inputs, set item 042 to 0. To enable auto-sensing for all available Aux
inputs, set item 042 to 255. For specications on all other available settings (i.e., settings for individual
inputs), refer to the table on the following page.
Note: When both item 042 AUTO INPUTS and item 041 SIMPLINK EN are enabled in the Installer Menu,
HDMI inputs will be detected by SIMPLINK, but the Auto Input(s) Sensing Feature will not function.
In the Installer Menu, an informational text code is displayed at the right of each Auto Inputs value, for
example:
PTC INSTALLER MENU
xxLT570H
CPU - CTV
042 AUTO INPUTS 225 765XXXX0
UPN 000-000-000-000 ASIC D279
PTC V#.##.### CPU V#.##.##.##
Each Auto Inputs text code consists of eight characters that identify the Aux input(s) for which auto-sensing
is enabled. The following table identies the Installer Menu text code input # for each Aux input that is
available on the LT570H TV models. The table also identies the Installer Menu item associated with each
Aux input. Remember that in order for auto-sensing to be enabled for an input, that input must also be
enabled in the Installer Menu.
Input # Assignments
Installer Menu
Display Code
Input #
Aux
Input
Installer Menu
Item Function
0 AV 039 REAR AUX EN
6 HDMI 1 035 HDMI1 ENABLE
7 HDMI 2 091 HDMI2 ENABLE
5 HDMI 3 092 HDMI3 ENABLE
AUTO INPUTS Display Code
This example illustrates Installer Menu item 042 value
225, which enables auto-sensing for all available Aux
inputs. The input #s in the text code (7, 6, 5, 0 in this
example) identify the enabled Aux inputs. See the Input
# Assignments table below for a listing of the LT570H
Aux inputs and their corresponding text code input #s.
The Auto Inputs Values table on the following page
shows the text codes for all item 042 values.
