PREPARATION
15
STAND INSTRUCTION
■
Image shown may differ from your TV.
Carefully place the TV screen side down on a
cushioned surface to protect the screen from
damage.
Assemble the parts of the Stand Body with the
Stand Base of the TV.
1
2
Assemble the TV as shown.
3
Installation
(Except 60PK250, 60PK540, 60PK550, 60PK280, 60PK290, 60PK550C)
Fix the 4 bolts securely using the holes in the
back of the TV.
4
Stand Body
Stand Base
M4x28
M5x14
x 3
x 4
To Next Page
