EXTERNAL EQUIPMENT SETUP
23
HDMI Connection
Connect the digital set-top box to
HHDDMMII//DDVVII IINN 11
,
22
or
33
No separate audio connection is necessary.
HDMI supports both audio and video.
1. How to connect
2. How to use
■
Tu r n o n t h e d i g i ta l s e t- to p b ox .
(
Refer to the owner’s manual for the digital set-top box.
)
■
Select the
HHDDMMII11
,
22
or
33
input source on the TV using the
IINNPPUUTT
button on the remote control.
2
1
HDMI-DTV
Horizontal Vertical
Frequency
(
KHz
)
Frequency
(
Hz
)
31 . 47 59 . 9 4
31 . 47 6 0 . 0 0
44.96 59.94
45.00 60.00
33.72 59.94
33.75 60.00
27.00 24.00
33.75 30.00
67.432 59.939
67.50 60.00
26.97 23.94
33.71 29.97
Resolution
720x480p
128 0 x 72 0 p
19 2 0 x 108 0 i
19 2 0 x 108 0 p
HDMI/DVI IN
2
1
HDMI-DTV OUTPUT
RGB IN(PC)
RS-232C IN
(CONTROL & SERVICE)
OPTICAL
DIGITAL
AUDIO OUT
AUDIO
(RGB/DVI)
1
GG
Check HDMI cable over version 1.3.
If the HDMI cables don’t support HDMI version
1.3, it can cause flickers or no screen display. In
this case use the latest cables that support HDMI
version 1.3.
GG
HDMI mode supports PCM, AC-3(Dolby Digital)
audio format.
