16
ENGLISH
Installing on a Wall
For proper ventilation, make sure the product is installed at least 100 mm (3.9 inches) away from the walls on every
side. Consult a professional installation company near you for details on installation.
100 mm (3.9inches)
100 mm (3.9inches)
100 mm (3.9inches)
100 mm (3.9inches)
• Use the screw holes as both of side when mounting the product.
- Screw hole as both of side: M10, Torque 17 kgf to 27 kgf (Both of side: 12 holes)
- Please use the 18 mm (0.70 inches) to 20 mm (0.78 inches) screws.
CAUTION
• Disconnect the power cord before moving or installing the monitor to avoid risk of electric shock.
• If you install the monitor on a ceiling or slanted wall, it may fall and result in injury. The product should be installed by
a professional installation company specified by the retail store.
• Do not over tighten the screws as this may damage the monitor and void your warranty.
• Any damage or injuries caused by misuse or use of improper accessories are not covered by the warranty.
NOTE
• Be sure to use the correct length.
To Next Page
