29
ENGLISH
PRODUCT SPECIFICATIONS
The product specifications below may be changed without prior notice due to upgrade of product functions.
“ ” refers to alternating current (AC), and “ ” refers to direct current (DC).
LCD screen Screen type Thin Film Transistor (TFT)
Liquid Crystal Display (LCD) Screen
Video signal Maximum resolution 3840 × 2160 @ 60 Hz (HDMI/ DisplayPort)
1920 × 1080 @ 60 Hz (DVI-D)
- This may not be supported on some OS or graphics card types.
Recommended resolution 3840 × 2160 @ 60 Hz (HDMI/ DisplayPort)
1920 × 1080 @ 60 Hz (DVI-D)
- This may not be supported on some OS or graphics card types.
Horizontal frequency 30 kHz to 135 kHz
Vertical frequency 56 Hz to 60 Hz
Synchronization Digital
Input / Output ports
Embedded battery Applied
Environmental
Conditions
Operating Temperature -30 °C to 50 °C (-22 °F à 122 °F)
Operating Humidity 5 % to 100 %
Storage Temperature -20 °C to 60 °C (-4 °F à 140 °F)
Storage Humidity 5 % to 100 %
86XE3FS
LCD screen Pixel Pitch 0.4935 mm (H) x 0.4935 mm (V)
Power Rated power AC 200-240 V~ 50/60 Hz 10.0 A
AC 100-240 V~ 50/60 Hz 20.0 A
(For Canada, Colombia, Mexico, Peru, Philippines, Taiwan, United
States)
Power Consumption On Mode: 1450 W (Typ.) / 1850 W (Max.)
Sleep Mode: ≤ 0.5 W
Standby Mode: ≤ 0.5 W
Dimensions (Width x Height x Depth) / Weight 1338mmx2100mmx187mm / 276kg
(52.6 inches x 82.6 inches x 7.3 inches / 608.4 lbs)
