21
ENGLISH
P
ower Connection
•
Pr
epare the waterpr
oof power cable for 30 Amp (10 A
WG).
•
Check power cable c
olor connection to the cir
cuit breaker
.
•
Connect the power cable to the outside thr
ough the hole for power cable only
.
•
Cord gr
ip within hole for power cable can pr
event to enter water or dust.
Cor
d Grip
Country
Live
Neutral
Ground
Europe
Brown
Blue
Green
North America
Black
White
Green & Y
ellow
India
Red
Black
Green & Y
ellow
Japan/ T
aiwan
Black
White
Green & Y
ellow
20
22
